Pictures for reference only, please check the datasheet

PWB2010LC

Name: PWB2010LC
Brand: Coilcraft
SKU: DFBA748-Y-PWB2010LC-109-C-0000-X-Y
Availability: InStock
Rating: 5 (2 reviews)

Manufacturer:

Coilcraft

Mfr. Part #:

PWB2010LC

Walsoon Tech #:

DFBA748-Y-PWB2010LC-109-C-0000-X-Y

Description:

Audio & Signal Transformers PWB Wideband RF 1:1 0.0035-125 MHz

Delivery:

Payment:

PayPal, Credit Card, Wire Transfer, Western Union

Add To BOM

In stock

Tips: Best quotation will be offered within 24h, upon receiving your quick RFQ.

Quick RFQ

Sell your excess inventory

PWB2010LC Details
Packing And Shipping
Payment Method
Quality Control

Coilcraft,PWB2010LC is available at Walsoon Tech.100% original and new guarantee. If comprehensive data for PWB2010LC to optimize the supply chain, including costdown, time-saving, cross references, parametric, counterfeit risk, alternative components, obsolescence management forecasts is expected, please contact our professional team.

Specification

Secondary coil impedance	320 mOhms
Insulation voltage	300 V
Frequency Range	3.5 kHz to 125 MHz
Termination type	SMD/SMT
Inductance	780 uH, 780 uH
Primary coil impedance	320 mOhms
工厂最小包装	250
寿命周期	量产
ROHS	yes
Length	6.77 mm
Width	6.48 mm
Height	4.45 mm
